Universal puller 3-arm pattern hydraulic 450x140mm

Industrial quality, 3 arms for optimum load distribution, non-tilting and gentle on material, Strong, ergonomically shaped cross beam, Hook red-hot drop-forged, All-steel hooks positively connected to the crossbar, With patented hook brake - quick adjustment and secure fixing of the hooks, at the push of a button, Can be used as internal puller by repositioning the hooks, Hydraulic spindle with hardened surface, wear resistant, Spindle remains smooth and clean - no need to grease or oil, Crosspiece can be combined with other spindle/hook designs and lengths from the GEDORE puller construction kit, Safety note: Controlled removal is only guaranteed when using a torque wrench

Features:

• Country of origin: Germany
• Customs tariff number: 82055980
• Contents (Qty of pieces): 1
• Net weight: 19,9 kg
• 1000 V insulated: No
• VDE certified: No
• 3D data available: No
• Usable clamping reach: 140 mm
• Clamping width (min.) internal pulling: 270 mm
• Clamping width (max.) internal pulling: 530 mm
• Width of hooked foot: 36 mm
• Usable depth of hooked foot: 28 mm
• Thickness of hooked foot at tip: 6,5 mm
• Tractive force (max.): 10 t
• reversible arms available: Yes
• Clamping bracket available: No
• Hook brake available: Yes
• Hook can be moved parallel: No
• Quick release lever available: No
• Spindle anti-slip device: Yes
• Hydraulic spindle available: Yes
• Screws included: No
• Can be retrofitted with hydraulic spindle: No
• Clamping width (max.) external pulling: 450 mm
• Total length: 137 mm
• Hydraulic spindle: 1.06/HSP3
• Graduation: No
• Anti-slip device on the spindle: No
• Type of use: deduct inside and outside
• Clamping width (min.) external pulling: 150 mm
