Fan puller, 2-arm pattern 80x80 mm
Ready for shipment in 6 workdays
- Item number:
- WS03601656937
- Manufacturer number:
- 1.18/0
- Weight:
- 0.24 kg
Fan puller, 2-arm pattern 80x80 mm
The tried and tested range for economical bearing removal, Can also be used with sliding hammer No. 1.35/1A
Features:
- Country of origin: Brazil
- Customs tariff number: 82055980
- Reach: compliant
- Contents (Qty of pieces): 1
- Net weight: 0,24 kg
- 1000 V insulated: No
- VDE certified: No
- 3D data available: No
- Usable clamping reach: 80 mm
- Spindle thread size: M 10 x 115
- Width of hooked foot: 12 mm
- Usable depth of hooked foot: 10 mm
- Thickness of hooked foot at tip: 3,0 mm
- Tractive force (max.): 1 t
- reversible arms available: No
- Clamping bracket available: No
- Number of arms: 2
- Hook brake available: No
- Spindle anti-slip device: No
- Hydraulic spindle available: No
- Screws included: No
- Can be retrofitted with hydraulic spindle: No
- Clamping width (max.) external pulling: 80 mm
