Side cutter 180 mm
Ready for shipment in 6 workdays
- Item number:
- WS03602910926
- Manufacturer number:
- 8314-180 TL
- Weight:
- 0.245 kg
Side cutter 180 mm
Acc. to DIN ISO 5749, Convex handle shape for a high force build-up (rowned surfaces/handles - i.e. which are hardly rounded - prevent unfavourable, punctual peak forces. As a result, the force is evenly spread across your hand.), With slender head, ideal for confined spaces, Induction-hardened precision cutting edges, hardness 63 - 65 HRC, For medium-hard wire 1.6 mm, GEDORE special hardened and tempered steel, drop-forged, oil-hardened and annealed, Model TC = chrome-plated, with blue dipped handles
Features:
- Country of origin: Austria
- Customs tariff number: 82032000
- Reach: compliant
- Contents (Qty of pieces): 1
- Total width: 51 mm
- Total height: 16 mm
- Net weight: 0,243 kg
- 1000 V insulated: No
- VDE certified: No
- Total length: 180 mm
- Material: Heat-treated steel
- Width of head 1: 26,0 mm
- Surface: steel-grey
- Head height 1: 25 mm
- Standard: DIN ISO 5749
- Handle design: dip-insulated
- Cutting edge length: 25 mm
- Cutting values: Hard wire: 2.5 mm / 10 AWG Medium hard wire: 3 mm / 9 AWG Soft wire: 4 mm / 6 AWG
- Hardness of cutting edge: 63 - 65 HRC
- Design non-sparking: No
- Opening spring present: No
- Blade shape: with facet
- Head thickness: 11,0 mm
- Handle colour: blue
- Thickness of point: 1,0 mm
- ESD Yes/No: No
- with cutting edge: Yes
- Hardening process: Induction hardened
- Bevel: with
