Mobile workbench with 7 drawers and vice
Ready for shipment in 6 workdays
- Item number:
- WS03606623050
- Manufacturer number:
- 1504 0511 S
- Weight:
- 116.2 kg
Drawers with one-hand operation and safety lock, Load capacity per drawer 40 kg, lower heavy-duty drawer 60 kg, Central locking with cylinder lock, Static load capacity 1000 kg, in mobile operation 500 kg, Dimensions: H 985 x W 1100 x D 550 mm, Ball-bearing guide rails, Can be individually equipped with lengthwise and crosswise dividers (can be ordered individually), Load capacity per drawer 40 kg, lower heavy-duty drawer 60 kg (not with No. 1504 1000), GEDORE High-performance chassis: Total load capacity 1000 kg, 750 kg when mobile, 2 roller-bearing GEDORE high-performance wheels (fixed castors Ø 200 mm), 2 ball-bearing mounted GEDORE smooth-running wheels (swivel castors Ø 125 mm), both with total brakes, The GEDORE trapezoidal axle construction secures smooth running, manoeuvrability and track-keeping also in case of maximum loads, Parallel vice: Sturdy forged design, Jaws and anvil plate induction hardened, Protected vice spindle and adjustable guide, The GEDORE trapezoidal axle construction secures smooth running, manoeuvrability and track-keeping also in case of maximum loads, 4 distance modules No. 1500 ED-70 K, Length- (LT) and crosswise (QT) dividers from zinc-plated sheet steel (can be ordered individually), Options: Can be equipped with GEDORE tool modules (1500 ES/1500 CT), Can be extended with rear panel No. R 1504 L or rear panel No. RT 1504 L, Further drawer combinations on request, Special colours and designs available on request, Delivery without tools and accessories
Features:
- Country of origin: Germany
- Customs tariff number: 94032080
- Reach: compliant
- Contents (Qty of pieces): 1
- Total width: 1.100 mm
- Total height: 985 mm
- Net weight: 112,48 kg
- 1000 V insulated: No
- VDE certified: No
- Total length: 550 mm
- Material: Sheet steel
- Version: Mobile workbench with 7 drawers and vice
- Surface: powder-coated
- Colour: GEDORE blue, RAL 5017
- Thickness (e.g. workplate): 30 mm
- Drawer type: 5x Type 1, H = 67 mm 1x Type 2, H = 137 mm 1x Type 3, H = 207 mm
- Number of crosswise dividers: 2
- Number of lengthwise dividers: 3
- Number of drawers: 7
- Load capacity: 750 kg
- Worktop dimensions: 1100 x 550 x 30 mm
- Single pull-out stop: No
- Lockable: Yes
- Number of shelves: 1
- Number of wheels: 4
- Working height: 985 mm
- Static load carrying capacity: 1000 kg
- Load capacity per drawer: 40 kg
- Load capacity heavy duty drawer: 60 kg
- Fixed roller diameter (2x): 200 mm
- Swivel castor diameter with brakes (2x): 125 mm
- Number of cabinets: 1
